DIN5685A/C stainless steel chain
DIN5685 stainless steel chain SUS304 AISI316
DIN5685 stainless steel chain in SUS304 / AISI316, polished, short or long link to the German standard.
Specifications
- Material
- SUS304, AISI316, AISI316L stainless steel
- Standard
- DIN 5685 A/C
- Type
- Short link (A) or long link (C)
- Surface treatment
- Polished
- Applications
- Marine, decorative, general purpose
DIN 5685 stainless steel chain follows the German general purpose chain standard in short link (form A) or long link (form C) versions, made in stainless steel for corrosion resistance.
Where DIN 5685 Stainless Chain Is Used
DIN 5685 designates calibrated short link (form A) and long link (form C) chain for general purpose use: hanging, lifting slings made on site, towing, barriers and decorative work. It is not a grade-marked lifting chain. The stainless steel version is chosen for marine, coastal and outdoor use.
Material and Surface Finish
Stainless steel chain in SUS304, AISI316 or AISI316L. Stainless steel is chosen for corrosion resistance in marine, food, chemical and outdoor environments. All standard and non-standard chains can be made in stainless steel. Finish is bright polished.
Sizes and Ordering
DIN 5685 is produced in diameters from 2 mm up to 13 mm, in short link (form A) and long link (form C). Weight and breaking load depend on the form and the diameter; send us the diameter and form you need and we will confirm the exact figures from our current catalogue. Confirm the stainless grade and form (A or C) with your order.
About Boyuan Metal
Nantong Boyuan Metal Technology Co., Ltd. manufactures and exports chain, wire rope and rigging hardware. Our range covers commercial, stainless steel, security and high tensile chains, including German standard and American standard chains. Custom sizes and non-standard chains can be produced to your drawing or sample.
