What is the most important factor of G80 lifting chain ?
Every G80 chain we supply meets the 4:1 safety factor per EN 818-2. Each batch is proof-load tested at 2.5 × WLL before leaving the factory
G80 lifting chains have a wide range of applications, covering lifting, construction, marine, logistics, mining, and many other fields. A common requirement across these diverse applications is "safety."
According to the EN818-2 standard, the working load of a G80 chain is one-quarter of its minimum breaking tensile force.
A safety factor of 4:1 is the core of the G80 chain.
All other specifications—breaking tensile force, stiffness, elongation, and fatigue life—are set around this safety baseline.
This 4:1 factor covers all the unexpected factors that might be encountered in the application scenarios you mentioned.
What to Check Besides the Safety Factor
The 4:1 factor only works if the rest of the system supports it. Check that the grade marking is legible on every link - an unmarked chain should not be used for lifting. Make sure the hooks, shackles and connecting links are rated for grade 80, because a weaker component in the assembly sets the limit for the whole system. And inspect the chain for stretch, cracks and wear before use and periodically in service.
Our Grade 80 Range
For load securement we supply our blue painted lashing chain, and for lifting duty our black oxide lifting chain - both grade 80, with hooks and fittings to match. Tell us the working load and the application and we will confirm the diameter.
Frequently Asked Questions
What does a 4:1 safety factor actually mean?
It means the minimum breaking force of the chain is at least four times its rated working load limit. The factor exists to cover the unexpected forces of real lifting - it is not spare capacity to work beyond the WLL.
Should I still inspect a new G80 chain?
Yes. The safety factor assumes the chain is in good condition. Check the grade marking, look for stretch, cracks and wear, and keep the matched fittings in the same condition.
Which fittings can I use with G80 chain?
Hooks, shackles and connecting links rated for grade 80. A lower-rated component in the assembly sets the limit for the whole system.
